Granite® 230 Granite 230
The Granite 230 Series, popular for its rich matte surface, is designed for heavy-duty jobs.
Width and Profile Options
* Break strength value is per inch of width. Example 2’’ (50.8mm) is 2000lbs (907.1847kg) or 3/4’’ (19.05mm) is 750lbs (340.194kg). ASTM D6775-02
** All Hole Pull Strength values are based on a 1’’ wide specimen. ASTM D4831
| Profile | Thickness | Break Strength * |
Hole Pull Strength ** |
Available Widths |
|---|---|---|---|---|
B05 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 400lbs (181.437kg) | 40lbs (18.144kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B05 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 400lbs (181.437kg) | 40lbs (18.144kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
|
B07 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 600lbf (272kgf) | 100lbs (45.359kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
3" (76.20 mm)
|
|
B07 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 600lbs (272.155kd) | 100lbs (45.359kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
4" (101.60 mm)
|
B10 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 High Flex |
.075" - .085", 1.91mm - 2.16mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Standard |
.095" - .105", 2.41mm - 2.67mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Grooved |
.095" - .105", 2.41mm - 2.67mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Beaded |
.150" - .170", 3.81mm - 4.32mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Ex Thick Grooved |
.125" - .135", 3.17mm - 3.43mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Super Heavy |
.140" - .160", 3.56mm - 4.06mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Super Heavy Grooved |
.140" - .160", 3.56mm - 4.06mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
C05 Coated Rope |
.230" - .240", 5.842mm - 6.096mm | 800lbs (362.874kg) | N/A |
1/4" (6.35 mm) Rope
|
C08 Coated Rope |
.285" - .300", 7.239mm - 7.62mm | 800lbs (362.874kg) | N/A |
5/16" (7.93 mm)
|
|
B30 Super Heavy Grooved |
.130" - .160", 3.30mm - 4.06mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B30 Super Thick |
.175" - .195", 4.45mm - 4.95mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B30 Super Thick Grooved |
.175" - .195", 4.45mm - 4.95mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
Buy a Sample
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,200lbf (544kgf)
Hole Pull: 100lbf (45kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $84.25 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,700lbf (771kgf)
Hole Pull: 100lbf (45kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $84.25 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 2,500lbf (1133kgf)
Hole Pull: 280lbf (127kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $98.60 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 4,400lbf (1995kgf)
Hole Pull: 240lbf (108kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $105.60 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 5,000lbf (2267kgf)
Hole Pull: 150lbf (68kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $114.40 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 2,000lbf (907kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 3/4" (44.45 mm)
Gloss: Low Gloss
Base Price: $95.95 / 50' Roll
Thickness: 0.130" (3.30 mm) - Extra Thick 2 Grooved (X2)
Break Strength: 2,000lbf (907kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 3/4" (44.45 mm)
Gloss: Low Gloss
Base Price: $131.55 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 500lbf (226kgf)
Hole Pull: 60lbf (27kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $52.50 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 625lbf (283kgf)
Hole Pull: 100lbf (45kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $52.50 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1,250lbf (566kgf)
Hole Pull: 250lbf (113kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $52.50 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 800lbf (362kgf)
Hole Pull: 100lbf (45kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $73.35 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,100lbf (498kgf)
Hole Pull: 100lbf (45kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $73.35 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 2,800lbf (1270kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $77.25 / 50' Roll
Thickness: 0.150" (3.81 mm) - Super Heavy (SH)
Break Strength: 2,800lbf (1270kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $127.80 / 50' Roll
Thickness: 0.100" (2.54 mm) - 2 Grooved (G2)
Break Strength: 2,800lbf (1270kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $99.20 / 50' Roll
Thickness: 0.130" (3.30 mm) - Extra Thick 2 Grooved (X2)
Break Strength: 2,800lbf (1270kgf)
Hole Pull: 250lbf (113kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $112.60 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 450lbf (204kgf)
Hole Pull: 90lbf (40kbf)
Width: 3/4" (19.05 mm)
Gloss: Low Gloss
Base Price: $44.55 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 825lbf (374kgf)
Hole Pull: 130lbf (58kgf)
Width: 3/4" (19.05 mm)
Gloss: Low Gloss
Base Price: $46.75 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 300lbf (136kgf)
Hole Pull: 50lbf (22kgf)
Width: 1/2" (12.70 mm)
Gloss: Low Gloss
Base Price: $41.05 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 550lbf (249kgf)
Hole Pull: 120lbf (54kbf)
Width: 1/2" (12.70 mm)
Gloss: Low Gloss
Base Price: $43.15 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 2,000lbf (907kgf)
Hole Pull: 75lbf (34kgf)
Width: 3" (76.20 mm)
Gloss: Low Gloss
Base Price: $134.85 / 50' Roll
Thickness: 0.055" (1.39 mm) - Ultra Flex (UF)
Break Strength: 5,400lbf (2449kgf)
Hole Pull: 320lbf (145kgf)
Width: 3" (76.20 mm)
Gloss: Low Gloss
Base Price: $164.65 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 2,700lbf (1224kgf)
Hole Pull: 75lbf (34kgf)
Width: 4" (101.60 mm)
Gloss: Low Gloss
Base Price: $192.90 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 200lbf (90kgf)
Hole Pull: 40lbf (18kgf)
Width: 3/8" (9.52 mm)
Gloss: Low Gloss
Base Price: $39.25 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 400lbf (181kgf)
Hole Pull: 100lbf (45kgf)
Width: 3/8" (9.52 mm)
Gloss: Low Gloss
Base Price: $41.25 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 350lbf (158kgf)
Hole Pull: 50lbf (22kgf)
Width: 5/8" (15.87 mm)
Gloss: Low Gloss
Base Price: $42.60 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 650lbf (294kgf)
Hole Pull: 130lbf (58kgf)
Width: 5/8" (15.87 mm)
Gloss: Low Gloss
Base Price: $44.85 / 50' Roll
Thickness: 0.235" (5.97 mm) - Coated Rope (CR)
Break Strength: 400lbf (181kgf)
Hole Pull: N/A
Width: 1/4" (6.35 mm) Rope
Gloss: Low Gloss
Base Price: $30.00 / 15' Roll
Thickness: 0.055" (1.39 mm) - Ultra Flex (UF)
Break Strength: 7,000lbf (3175kgf)
Hole Pull: 320lbf (145kgf)
Width: 4" (101.60 mm)
Gloss: Low Gloss
Base Price: $211.90 / 50' Roll
