Beta® 583 Beta 583
With an 82A Shore hardness, the Beta 583 series has a harder PVC coating with a high gloss finish. It has good chemical resistance, and comes in a variety of colors, widths, and profiles, all detailed below. It is used frequently in sporting goods applications.
Width and Profile Options
* Break strength value is per inch of width. Example 2’’ (50.8mm) is 2000lbs (907.1847kg) or 3/4’’ (19.05mm) is 750lbs (340.194kg). ASTM D6775-02
** All Buckle Pull Strength values are based on a 1’’ wide specimen. ASTM D4831
| Profile | Thickness | Break Strength * |
Buckle Pull Strength ** |
Available Widths |
|---|---|---|---|---|
B05 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 400lbs (181.437kg) | 40lbs (18.144kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B05 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 400lbs (181.437kg) | 40lbs (18.144kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
|
B07 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 600lbs (272.155kd) | 100lbs (45.359kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
3" (76.20 mm)
|
|
B07 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 600lbs (272.155kd) | 100lbs (45.359kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
1" (25.40 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
4" (101.60 mm)
|
B10 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 High Flex |
.075" - .085", 1.91mm - 2.16mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Standard |
.095" - .105", 2.41mm - 2.67mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Grooved |
.095" - .105", 2.41mm - 2.67mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Beaded |
.150" - .170", 3.81mm - 4.32mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Ex Thick Grooved |
.125" - .135", 3.17mm - 3.43mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Super Heavy |
.140" - .160", 3.56mm - 4.06mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
B10 Super Heavy Grooved |
.140" - .160", 3.56mm - 4.06mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/8" (9.52 mm)
1/2" (12.70 mm)
9/16" (14.28 mm)
5/8" (15.87 mm)
3/4" (19.05 mm)
7/8" (22.22 mm)
1" (25.40 mm)
1 1/8" (28.57 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
2 1/2" (63.50 mm)
3" (76.20 mm)
4" (101.60 mm)
|
C05 Coated Rope |
.230" - .240", 5.842mm - 6.096mm | 800lbs (362.874kg) | N/A |
1/4" (6.35 mm) Rope
|
C08 Coated Rope |
.285" - .300", 7.239mm - 7.62mm | 800lbs (362.874kg) | N/A |
5/16" (7.93 mm)
|
|
B30 Super Heavy Grooved |
.130" - .160", 3.30mm - 4.06mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B30 Super Thick |
.175" - .195", 4.45mm - 4.95mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
B30 Super Thick Grooved |
.175" - .195", 4.45mm - 4.95mm | 3000lbs (1360.777kg) | 700lbs (317.515kg) |
3/4" (19.05 mm)
1" (25.40 mm)
1 1/4" (31.75 mm)
1 1/2" (38.10 mm)
2" (50.80 mm)
|
Buy a Sample
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1000lbs (453.592kg)
Buckel Pull: 200lbs (90.719kg)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $67.80 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1500lbs (680.389kg)
Buckel Pull: 200lbs (90.719kg)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $67.80 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1500lbs (680.389kg)
Buckel Pull: 700lbs (317.515kg)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $80.70 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 3000lbs (1360.777kg)
Buckel Pull: 700lbs (317.515kg)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $85.00 / 50' Roll
Thickness: 0.055" (1.39 mm) - Ultra Flex (UF)
Break Strength: 3000lbs (1360.777kg)
Buckel Pull: 700lbs (317.515kg)
Width: 2" (50.80 mm)
Gloss: High Gloss
Base Price: $92.10 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 500lbs (226.796kg)
Buckel Pull: 40lbs (18.144kg)
Width: 1" (25.40 mm)
Gloss: High Gloss
Base Price: $42.25 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1000lbs (453.592kg)
Buckel Pull: 200lbs (90.719kg)
Width: 1" (25.40 mm)
Gloss: High Gloss
Base Price: $45.30 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1000lbs (453.592kg)
Buckel Pull: 40lbs (18.144kg)
Width: 1 1/2" (38.10 mm)
Gloss: High Gloss
Base Price: $59.10 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 1500lbs (680.389kg)
Buckel Pull: 700lbs (317.515kg)
Width: 1 1/2" (38.10 mm)
Gloss: High Gloss
Base Price: $62.20 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 400lbs (181.437kg)
Buckel Pull: 40lbs (18.144kg)
Width: 3/4" (19.05 mm)
Gloss: High Gloss
Base Price: $35.95 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 800lbs (362.874kg)
Buckel Pull: 40lbs (18.144kg)
Width: 3/4" (19.05 mm)
Gloss: High Gloss
Base Price: $38.35 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1500lbs (680.389kg)
Buckel Pull: 700lbs (317.515kg)
Width: 3" (76.20 mm)
Gloss: High Gloss
Base Price: $106.90 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 400lbs (181.437kg)
Buckel Pull: 40lbs (18.144kg)
Width: 5/8" (15.87 mm)
Gloss: High Gloss
Base Price: $34.30 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 500lbs (226.796kg)
Buckel Pull: 40lbs (18.144kg)
Width: 5/8" (15.87 mm)
Gloss: High Gloss
Base Price: $36.70 / 50' Roll
Thickness: 0.235" (5.97 mm) - Coated Rope (CR)
Break Strength: 400lbs (181.437kg)
Buckel Pull: 40lbs (18.144kg)
Width: 1/4" (6.35 mm) Rope
Gloss: High Gloss
Base Price: $30.00 / 15' Roll
