TPE 760 TPE 760
With an 30A Shore hardness, the TPE 760 series was developed for applications where a soft touch and extra grip is needed.
Width and Profile Options
* Break strength value is per inch of width. Example 2’’ (50.8mm) is 2000lbs (907.1847kg) or 3/4’’ (19.05mm) is 750lbs (340.194kg). ASTM D6775-02
** All Hole Pull Strength values are based on a 1’’ wide specimen. ASTM D4831
| Profile | Thickness | Break Strength * |
Hole Pull Strength ** |
Available Widths |
|---|---|---|---|---|
B07 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 625lbf (283kgf) | 100lbf (45kgf) |
1" (25.40 mm)
1 1/2" (38.10 mm)
|
B10 Thin Flex |
.045" - .055", 1.14mm - 1.39mm | 1,250lbf (566kgf) | 250lbf (113kgf) |
1" (25.40 mm)
|
B10 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 1,750lbf (793kgf) | 290lbf (131kgf) |
1 1/2" (38.10 mm)
|
B10 High Flex |
.075" - .085", 1.91mm - 2.16mm | 1,000lbf (453kgf) | 200lbf (90kgf) |
1" (25.40 mm)
|
Buy a Sample
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 625lbf (283kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $50.10 / 50' Roll
Thickness: 0.080" (2.03 mm) - High Flex (HF)
Break Strength: 625lbf (283kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $73.35 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,100lbf (498kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $70.90 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1,250lbf (566kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $51.30 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 2,800lbf (1270kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $78.75 / 50' Roll
