TPE 711 TPE 711
With an 70A Shore hardness, the TPE 711 series is similar to our Granite 230 series, but slightly softer and has a low gloss finish.
Width and Profile Options
* Break strength value is per inch of width. Example 2’’ (50.8mm) is 2000lbs (907.1847kg) or 3/4’’ (19.05mm) is 750lbs (340.194kg). ASTM D6775-02
** All Hole Pull Strength values are based on a 1’’ wide specimen. ASTM D4831
| Profile | Thickness | Break Strength * |
Hole Pull Strength ** |
Available Widths |
|---|---|---|---|---|
B07 Ultra Thin |
.030" - .040", .76mm - 1.02mm | 625lbf (283kgf) | 100lbf (45kgf) |
3/4" (19.05 mm)
1" (25.40 mm)
2" (50.80 mm)
|
B15 Thin Flex |
.045" - .055", 1.14mm - 1.39mm | 1,250lbf (566kgf) | 250lbf (113kgf) |
3/4" (19.05 mm)
1" (25.40 mm)
2" (50.80 mm)
|
B10 Super Flex |
.055" - .065", 1.40mm - 1.65mm | 1,750lbf (793kgf) | 290lbf (131kgf) |
2" (50.80 mm)
|
Buy a Sample
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 1,700lbf (771kgf)
Hole Pull: 100lbf (45kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $71.40 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 2,500lbf (1133kgf)
Hole Pull: 200lbf (90kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $85.00 / 50' Roll
Thickness: 0.060" (1.52 mm) - Super Flex (SF)
Break Strength: 3,500lbf (1587kgf)
Hole Pull: 290lbf (131kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $89.50 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 625lbf (283kgf)
Hole Pull: 100lbf (45kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $44.50 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1,250lbf (566kgf)
Hole Pull: 250lbf (113kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $47.70 / 50' Roll
Thickness: 0.035'' (0.88 mm) - Ultra Thin (UT)
Break Strength: 450lbf (204kgf)
Hole Pull: 90lbf (40kbf)
Width: 3/4" (19.05 mm)
Gloss: Low Gloss
Base Price: $37.90 / 50' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 825lbf (374kgf)
Hole Pull: 130lbf (58kgf)
Width: 3/4" (19.05 mm)
Gloss: Low Gloss
Base Price: $40.35 / 50' Roll
