FR 610 FR 610
With an 78A Shore hardness, the FR 610 series is our fire retardant product line. It passes the 5 second flame test.
Width and Profile Options
* Break strength value is per inch of width. Example 2’’ (50.8mm) is 2000lbs (907.1847kg) or 3/4’’ (19.05mm) is 750lbs (340.194kg). ASTM D6775-02
** All Hole Pull Strength values are based on a 1’’ wide specimen. ASTM D4831
| Profile | Thickness | Break Strength * |
Hole Pull Strength ** |
Available Widths |
|---|---|---|---|---|
B21 Mega Thin |
.035" - .045", .889mm - 1.14mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
3/4" (19.05 mm)
|
|
B17 Thin Flex |
.045" - .055", 1.14mm - 1.39mm | 1000lbs (453.592kg) | 200lbs (90.719kg) |
1 1/2" (38.10 mm)
|
Buy a Sample
Thickness: 0.040" (1.02 mm) - Mega Thin (MT)
Break Strength: 1,400lbf (635kgf)
Hole Pull: 70lbf (31kgf)
Width: 3/4" (19.05 mm)
Gloss: Low Gloss
Base Price: $73.40 / 25' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 2,100lbf (952kgf)
Hole Pull: 420lbf (190kgf)
Width: 1 1/2" (38.10 mm)
Gloss: Low Gloss
Base Price: $91.73 / 25' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 1,700lbf (771kgf)
Width: 1" (25.40 mm)
Gloss: Low Gloss
Base Price: $76.80 / 25' Roll
Thickness: 0.050" (1.27 mm) - Thin Flex (TF)
Break Strength: 3,400lbf (1542kgf)
Hole Pull: 480lbf (217kgf)
Width: 2" (50.80 mm)
Gloss: Low Gloss
Base Price: $119.35 / 25' Roll
